Max Work Dia.: 100 mm
Max Module (pitch) 4 mm 6 DP
Max Axial Slide Travel 120 mm
Min/Max Number of Teeth
-Standard 2 Start Index Drive 5/36
-Optional 2 Start Index Drive 4/24
-Optional 4 Start Index Drive 2/12
Max Hob Head Swivel +/-40 degrees
Max Table Speed 50 - 150/min
Hob Shift Travel 120 mm
Hob Speeds 180 - 400/min
Axial Feed 12 Steps Via Change Gears .5 - 6.96 mm/rev
Center Distance Btwn Work & Hobb 25-110 mm
Work Table Dia. 150 mm
Table Bore Dia 63 mm
Hobb Arbor Dia. 27 mm
Max Hobb Size 100 mm x 140 mm length
